Compact, mobile industrial vacuum cleaner for direct extraction of fumes and gases generated during MIG-MAG welding. It has an automatic start/stop function, so the welder only needs to use the lamp. An additional hose can be connected to allow for minor cleaning of the working air.
The Fumevac Welding Fume Extractor is a compact, mobile industrial fume extractor suitable for transport to work areas where welding operations are carried out. It is designed to extract fumes and gases generated during mig-core welding directly at the source.
In a machine shop or carpentry workshop, having a means of extracting welding fumes has significant benefits for the health of operators and, in the long term, for improved production efficiency. In fact, the Fumevac allows localised extraction of fumes directly to the processing area while protecting the health of the welder.
This vacuum cleaner is equipped with an automatic start/stop device that allows the machine to be switched on and off without the welder having to perform any operation, except for the use of the welding lamp.
There is also a secondary function, which allows you to connect a hose to the vacuum cleaner and clean the working air less.
Detailed specifications and technical data. Download the full datasheet to have all the information you need at your fingertips.
| Fumevac, welding fume extractor | |
|---|---|
| Power supply | 230-50 1 V-Hz |
| Power | 1,1 kW |
| Maximum depression | 2,400 mmH2O |
| Maximum airflow speed | 180 m³/hour |
| Spray nozzle | 50 mm |
| Primary filter | Cartridge |
| Surface area – diameter | 7.500 cm² – 245 mm |
| Dimensions | 40 x 56 x 86 m |
| Weight | 25 kg |
